- is_customized: Yes
- Max. Power: 100W
- Number of Cells: 32
- Size: 1050*530*3MM
- Material: Monocrystalline Silicon
- Model Number: RGN32-100W
- Nominal Capacity: 12V
- Foldable Solar Panel: No
- Flexible Solar Panel: Yes
- Number of Panels: >20
- Type: Solar Panel
- Brand Name: dgsunlight
- Origin: Mainland China
- Certification: CE,RoHS
- Maximum power(Pmax): 100w
- Open circuit voltage(Voc): 19.2v
- Short circuit current(Isc): 6.68A
- Maximum power voltage(Vmp): 16v
- Maximum power current(Imp): 6.25A
- Weight: 1.9kg
Shipping Information
This product we set up warehouse in United States, Germany, Poland, Spain, Czech Republic and Belgium，When you buy it,if you are in EU or US, we will ship to your country and it will be fast delivery.
However，
the zip code in Spain that starts with 35, 38, 51, 52.
the zip code in France that starts with 97
the zip code in Portugal that starts with 9.
Above zone for local shipping company,they are remote area.there is no logistics shipping to above zone from Spain or Belgium.Remote areas need to charge extra freight. we will not ship to above zone,please not place order with above address,thanks.
Packing List
100W Solar Panel= 1 pcs 100W flexible solar panel
200W Solar Panel= 2 pcs 100W flexible solar panel
300W Solar Panel= 3 pcs 100W flexible solar panel
400W Solar Panel= 4 pcs 100W flexible solar panel
500W Solar Panel= 5 pcs 100W flexible solar panel
600W Solar Panel= 6 pcs 100W flexible solar panel
800W Solar Panel= 8 pcs 100W flexible solar panel
100w solar panel system packing list
1pcs 100w flexible solar panel
1pcs 10A 12V/24V solar panel controller
1set cable with battery clips
1set cable with PV solar connector
200w solar panel system packing list
2pcs 100w flexible solar panel
1pcs 20A 12V/24V solar panel controller
1set cable with battery clips
1set cable with PV solar connector
1pair 2 in 1 solar adapter
300w solar panel kit packing list
100W 16V solar panel *3
30A 12V/24V solar charger regulator *1
3 meter extend cable *1
1 meter cable with alligator clips *1
3-in-1 PV parallel adapter *1
|
MODEL |
10A |
20A |
30A |
|
Battery Voltage |
12V/24V Auto |
||
|
Charging Current |
10A |
20A |
30A |
|
Discharging Current |
10A |
10A |
10A |
|
Max Solar input |
48V(for 24V battery) 24V(for 12V battery) |
||
|
Equalization |
14.4V(Sealed) 14.2V(Gel) 14.6V(Flood) |
||
|
Float charge |
13.7V(defaul,adjustable) |
||
|
Discharge stop |
10.7V(defaul,adjustable) |
||
|
Discharge reconnect |
12.6V(defaul,adjustable) |
||
|
Charge reconnect |
13V |
||
|
Voltage of open light |
Solar Panel 8V(Light lights delay) |
||
|
Voltage of close light |
Solar Panel 8V(Light off delay) |
||
|
USB output |
5V/3A |
||
|
Self-consume |
<10mA |
||
|
Operating temperature |
-35°C~+60°C |
||
|
Size/weight |
133.5*70*35mm |
165g |
|
Different with traditional solar panels which are rigid and often enclosed in tempered glass, the 100W Flexible Solar Panel is anything but traditional. The 100W Flexible Solar Panel is thin and capable of flexing up to 30 degrees that can easily be installed on curved surfaces, high efficiency up to 21% with small size for big power output, light weight just 1.9kg(±0.1kg) only a quarter of its traditional 100W glass solar panel. This panel can also be used for various applications, including providing power on a boat, van, golf car, tricycle, tent roof, even though hanged on window to power the lights and other DC applications. The 100W solar panel can charge the 12V or 24V battery or charge the 3.7V, 6V, 9V devices with a regulator。
Advantages
High Efficient
High solar cell efficiency: Monocrystalline 21%
Protection
Bypass diodes minimize power drop caused by shade and ensure excellent performance in low-light environments
Extremely Flexible
This panel is capable of meeting a wide range of applications where standard panels can be inconvenient to mount, such as on the curved roof of an airstream
Ultra Lightweight
Thanks to advanced polymer materials, this product weighs 70% less than conventional solar panels, making transportation and installation a breeze
Super Thin
Hardly noticeable, the 100W Lightweight Panel laid flat is only a tenth of an inch tall! Approximately 95% thinner than its rigid counterpart, this panel is ideal for a stealthy solar setup
Highly Durable
Rigorously tested, the 100W panel was designed to withstand extreme wind and snow loads
Easy to install: Metal holes in the corners of the product for fixing screws and mounting.
Electrical Characteristics
Max Power 100W
Max Power voltage 16V
Max Power Current 6.25A
Open Circuit Voltage 19.2V
Short Circuit Current 6.68A
Number of cells in Series 32
Cell size 125X125mm
Mechanical Characteristics
Dimension 1050X530X2.5mm
Weight 1.9kg(±0.1kg)
Cable 0.9 meter 2X2.5mm
Thermal Characteristics
Temperature coefficient of Pmax -0.38%/℃
Temperature coefficient of Voc -60.5mV/℃
Temperature coefficient of Isc 2.2mA/℃
NOTC 47℃+/-2℃
Operating Temperature -20℃ – +65℃
